GS302 Auto paper core loading/unloading machine/core loader
General technical parameters(customized):
Width | 1300/1600mm(match with slitting machine) |
Paper core inner diameter | 24.5mm-76.2mm |
Working air pressure | 5kg/cm² |
Auto loading control | By air cylinder |
Operation | By hand valve |
Mould | Size match with slitting width |
Application:
This paper core loading and unloading machine is specially used for automatically wearing tapes paper core on rewinding shafts and auro unloading tapes rolls from rewinding shafts.
Features:
This machine is one set of standard rewinding machine.
It has several features:
A) Simple and easy to operate.
B) A necessary process matching with slitting machine.
C) Auto loading paper core on rewinding shafts and unloading tape rolls from rewinding shafts.
